SCVETechnical ParametersDetailed parameter analysis to assist equipment selection and integration
-
Product Model SF35-6R
SF35-10R
SF35-12R
-
Torque
(N.M)6
10
12
-
Rotational Speed
(rpm)17
17
17
-
Rated Voltage (V)230
230
230
-
Rated
Power
(W)155
165
170
-
Frequency (Hz)50
50
50
-
Rated Current (A)：0.68
0.71
0.75
-
Limit Number of Turns
(turn)：42
42
42
-
Protection Class (IP)IP44
IP44
IP44
-
Working Time (min) ≥4
≥4
≥4
-
Net Weight
(kg)1.7
1.7
1.7
SCVEProduct AdvantagesDetailed parameter analysis to assist equipment selection and integration
-
Mechanical Limit
-
Built-in Receiver
-
Low Noise Processing
SCVEProduct CaseThe case demonstrates strength and stable operation can be traced.
